KEY FEATURES

1. Dual Source of Charging From Solar Power as well as from Grid Power.
2. Power Card with inbuilt PWM Based Solar Charge Controller of 50A for maximum utilization of solar power.
3. Intelligently selection of battery boost voltage to avoid un-necessary heating of battery during charging.
4. Intelligently selection of battery low shutdown for longer backup according to load conditions.
5. Regular priority of solar power to give maximum benefits from solar energy to run the load or charge the battery.
6. 30% AVR function below 180V Grid Input.
7. All selection switch on front side,no switch at back side.
8. Storage of Solar Power Consumed from the day of installation.
9. CC & CV mode for every 0.1V increment of battery voltage.
10. Maximum usage of solar power to minimize the electricity bill and being eco-friendly.
11. Display Maximum and useful parameters on  LCD according to customers needs.
12. Pure Sine Wave output with less harmonic distortions.
13. Double Stage MOSFET over current protection at priority.
14. Thermal trip with auto recovery.
15. Upgradeable to IOT Functioning.

DISPLAYING PARAMETERS ON LCD

• Model VA & Capacity
• Battery Voltage
• PV Charging Current
• Grid I/P Voltage
• Grid Charging Current
• AC Output Voltage
• Discharging Current
• Load Percentage
• Mode UPS/Normal
• Battery Status
• PV Status
• Grid Status
• Load Status
• Consumed PV Power
• Instant PV Power
• Thermal trip
• PV Reverse
• Short-Circuit
• Battery Low/High
• Grid MCB/fuse Trip
• Battery Overload trip

PROTECTIONS

Thermal Trip |  Battery High/Low  | Short-Circuit | PV Reverse | Grid MCB/Fuse Tip | Overload Trip

TECHNICAL SPECIFICATIONS
