| Nominal Voltage |
100ah |
| Nominal Capacity |
96ah |
| Energy |
9600Wh |
| End Voltage |
80V |
| Charging Voltage |
116.8 |
| Cell Chemistry |
Prismatic(3.2V6Ah) |
| Cell Arrangement |
2x16S7P |
| Discharging Current(Cont. ) |
Up to 40 Amps |
| Discharging Current(Peak ) |
100 Amps (Max) |
| Charging Current(Max.) |
Up to 20 Amps |
| Charging/Discharging Port |
Anderson/2-Pin |
| Warranty |
15Years |
| Life Cycle |
3000 Cycle |
| Pack Type |
Metal Box/FRP |
| Over Voltage Protection |
Yes |
| Under Voltage Protection |
Yes(80V) |
| Over Current Protection |
Yes |
| Reverse Polarity |
NA |
| Cell Balancing |
Yes |
| Dimension(LxWxH) |
290x290x185 |
